Fluid Mechanics System

Name: Fluid Mechanics System
Brand: MECHMATICS ENGINEERING PVT. LTD.
Price: 500000.0 INR
Availability: InStock

Price 500000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Fluid Mechanics System Specification

Equipment Type
Fluid Mechanics Test Bench

Material
Mild Steel

Processing Type
Batch Type Operation

Condition
New

Technology
Hydraulic and Pneumatic System Principles

Dimension (L*W*H)
1400 x 700 x 1600 mm

Power Mode
Electric

Voltage
220-240 V AC, 50 Hz

Power Consumption
1.5 kW

Pressure Output
0-10 bar

Application
Lab Testing, Educational Demonstrations, and Research

Coating Type
Powder Coated

Accessories
Instruction Manual, Connecting Hoses, Fittings

Calibration Certificates
Supplied with NABL Traceable Certifications

Controller Type
Automated Microprocessor-Based Control Panel

Noise Level
< 60 dB(A)

Flow Rate
0.5 to 10 LPM

Pipe Material
Clear Acrylic and SS Fittings

Test Setup Inclusion
Venturimeter, Orificemeter, and Pitot Tube Units

Safety Features
Overload Protection, Emergency Stop Switch

Reservoir Capacity
30 Liters

Display Type
Digital Flow and Pressure Indicators

Working Speed
Variable, Up to 2000 RPM

Mobility
Mounted on Lockable Castor Wheels

Operating Temperature Range
10C to 45C

Colour
Blue & Grey

Fluid Mechanics System About

Product Overview

Comprehensive range of advanced fluid measurement devices designed for research applications, offering high-precision flow analysis, visualization, and particle measurement capabilities.

Particle Image Velocimetry (PIV) Systems

2D2C PIV System (Two-Dimensional, Two-Component Velocity Measurement)
Stereo PIV System (2D3C Three Velocity Components)
High-Speed PIV System
Global Sizing Velocimetry (GSV) System

Micro-PIV Systems

2D Micro-PIV System
Confocal Micro-PIV System
High-Speed Micro-PIV System

LDV / PDPA Systems

Laser Doppler Velocimetry (LDV) Systems: 1D, 2D, and 3D Configurations
Phase Doppler Particle Analyzer (PDPA) Systems

PLIF Systems (Planar Laser-Induced Fluorescence)

Standard PLIF System
Stereo PLIF System
High-Speed PLIF System

Hot-Wire Anemometry Systems

1D, 2D, and 3D Measurement Systems
Wide Range of Probes Available

Volumetric Measurement System

V3V System (3D3C Full-Volume PIV Measurement)

Accessories and Additional Equipment

Tracer Particles (Various Types)
Particle Seeding / Dispersion Systems
Traverse Mechanisms
Visualization Cameras and Laser Systems

Reliable Automated Control & Digital Accuracy

An automated microprocessor-based control panel simplifies operation, delivering precise flow and pressure data via digital indicators. The system is uniquely suited for constantly changing test parameters, offering users real-time adjustments and immediate feedback for accurate experimentation.

Comprehensive Test Setup & Premium Build

Supplied with a venturimeter, orificemeter, and pitot tube units, the system covers essential fluid dynamics experiments. Constructed with clear acrylic pipes and stainless steel (SS) fittings, it ensures durability, clarity for observation, and resistance to corrosion, with a large 30-liter reservoir supporting extended operations.

Safety First, Mobility Always

Integrated overload protection and a prominent emergency stop switch ensure operator safety in laboratory settings. Mounted on lockable castor wheels, the system can be easily moved or securely stationed, enabling versatile usage in diverse environments.

FAQ's of Fluid Mechanics System:

Q: How does the automated microprocessor-based control panel enhance the operation of the Fluid Mechanics System?

A: The automated microprocessor-based control panel simplifies system management, providing users with real-time control and monitoring of working speed and flow rates. This enables precise adjustment of settings, resulting in accurate and consistent experimental data.

Q: What fluid mechanics experiments can be conducted with the included test setup?

A: The included venturimeter, orificemeter, and pitot tube units facilitate a wide range of experiments, including flow rate measurements, pressure loss studies, and velocity profile analysis-making the system suitable for comprehensive academic and research applications.

Q: When should I rely on the overload protection and emergency stop features?

A: These safety features should be utilized whenever abnormal operating conditions, such as excessive load or unexpected emergencies, arise. They help prevent equipment damage and protect users from potential hazards during testing.

Q: Where can the Fluid Mechanics System be positioned within a facility?

A: Thanks to its lockable castor wheels, the system is designed for mobility and flexibility, allowing it to be stationed in various laboratory or industrial settings. The wheels can be locked to ensure stability during experimentation.

Q: What benefits does NABL traceable calibration certification provide?

A: NABL traceable calibration certificates assure users of measurement reliability and compliance with international standards, ensuring that the data recorded by the system's digital indicators are both accurate and trustworthy.

Q: How is the noise level managed during operation?

A: The system is engineered to operate below 60 dB(A), ensuring a quiet laboratory environment even at maximum speed, thereby supporting communication and concentration for the users.
