Reciprocating Balancing Apparatus

Name: Reciprocating Balancing Apparatus
Brand: MECHMATICS ENGINEERING PVT. LTD.
Price: 35000 INR
Availability: InStock

Price 35000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Reciprocating Balancing Apparatus Specification

Features
Good Quality

Shape
Rectangular

Power Supply
Electric

Usage
Industrial

Size
Standard Sizes

Product Type
Balancing Machine

Voltage
110-215 Volt (v)

Material
MS

Reciprocating Balancing Apparatus Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
5-10 Days

Main Domestic Market
All India

About Reciprocating Balancing Apparatus

The apparatus is used to study and analyze the oscillations and vibrations and how to eliminate or diminish them. A shaft mounted on bearings is coupled by pulleys to an electrical motor with variable speed. The unit is fixed to the support structure by means of springs which make the unit oscillate in case there are vibrationsThis shaft has 4 discs coupled: one of them is the pulley, 2 are balancing discs and at the end, there is a graduated disc. The discs have drills to proceed, through fixing the masses, to the system destabilization and then to its subsequent balancing.On another hand, it can be coupled to our system a piston whose movement will be an alternative perpendicular to the shaft. The connection of the piston to the shaft is made with a connecting rod. A ruler can be used to see easily the measure system displacement with a needle placed at the side. The unit is supplied with a set of masses and weights of different values for doing the experiments
Specifications:1.Table Size: 600 x 300 x 600 mm2.1/8 HP 6000 rpm DC Motor with a controller3.No. of Discs: 4 Nos.4.One Piston Cylinder Arrangement5.No. of Weights: 8 Nos. 5. Detailed Technical Manual and On-site Training Service Required:1.230 V.A.C. single phase supply.2.Rigid platform or sturdy table with preferably a solid foundation.3.Handheld Tachometer
