Whirling of Shaft Apparatus

25800 INR/Unit

Get a Price/Quote

Product Details:

Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Whirling of Shaft Apparatus Price And Quantity

Price 25800 INR/Unit
Minimum Order Quantity 1 Unit

Whirling of Shaft Apparatus Trade Information

Main Domestic Market All India

Product Description

With our-in depth knowledge in the relevant industry, we are supplying quality assured range of Whirling of Shaft Apparatus. Being tested on various parameters of quality by our skilled quality controllers, we ensure its unbeatable quality and durability. Our adroit professionals manufacture this product by use of latest machine and premium quality components in adherence to the set industry standards. Clients can avail the entire range from us at reasonable prices.

Features:

Robust construction
High functionality
Excellent all round performance

Whirling of Shafts apparatus shows how shafts vibrate transversely and 'whirl™ at a certain rotation frequency. This helps engineers understand possible problems with long shafts and allow for them in their designs.The main part thick powder coated frame that hold a variable speed motor which turns the horizontal test shaft. Two bearings hold the shaft, one bearing at the 'driven end™ and the other bearing at the 'tail end™ of the shaft. The tail end bearing slides in its housing to allow the shaft length to change as it 'whirls™. Similar to a beam on two simple knife-edge supports, both bearings allow free angular shaft movement (free ends condition). Also supplied with the equipment are extra bearings that restrict angular movement when fitted, to give 'fixed ends™.

The apparatus is a set of test shafts of different length and diameter to show how these properties affect whirling. Also supplied is a set of weights to show how concentrated loads affect whirling. One weight has an extra hole to make it an eccentric load.
