Micro Bubble Generator

Name: Micro Bubble Generator
Brand: MECHMATICS ENGINEERING PVT. LTD.
Price: 500000.0 INR
Availability: InStock

Price 500000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Micro Bubble Generator Specification

Equipment Type
Micro Bubble Generator

Material
Stainless Steel

Processing Type
Standard

Condition
New

Technology
Micro Bubble Generation Technology

Dimension (L*W*H)
450 x 230 x 320 mm

Power Mode
Electric

Voltage
220V, 50/60 Hz

Power Consumption
0.55 kW

Pressure Output
0.2-0.5 MPa

Application
Fine Bubble Aeration, Wastewater Treatment, Aquaculture, Cleaning

Coating Type
Corrosion-Resistant Coating

Accessories
Connecting Hose, Power Cord, Instruction Manual

Bubble Size
10-50 micron

Water Proof Rating
IP55

Working Speed
800-1200 RPM

Control System
Automatic / Manual Switch

Installation
Portable, Easy to Install

Gas Flow Rate
5-20 L/min

Noise Level
<60 dB

Inlet/Outlet Size
1 inch

Weight
18 kg

Micro Bubble Generator About

The Micro Bubble Generator is designed primarily for laboratory use to support research and development related to microbubble technology. The system enables controlled generation of microbubbles and provides measurement data on bubble size distribution within the test tank.

Operating Principle

This system utilizes a self-aspirating swirling (rotational) method for bubble generation.

Gas is drawn in through the inlet
The pump impeller applies shear force to break the gas into extremely fine bubbles
This process produces stable and uniform microbubbles

Compared to conventional pressurized methods, this technique has been shown to provide enhanced biological activity in various research applications.

Basic Specifications

Model: FEL-MB2010
Dimensions: 500 (W) 400 (D) 220 (H) mm
Liquid Flow Rate: 4 L/min
Gas Flow Rate: 5 20 mL/min
Water Capacity: Approx. 4 L
Power Supply: AC 100 V

Key Features

Enables experiments under conditions with known bubble size distribution
Produces uniform microbubble size distribution
Self-aspirating system eliminates the need for an air compressor
Compatible with various gases, ensuring safe and flexible operation
Suitable for experiments with small sample volumes
Compact design for space-saving laboratory use

Measurement & Analysis

Bubble size distribution data is provided along with the system
Measurements are conducted using an ultrasonic bubble size distribution analyzer (ABS)
Supports detailed analysis of microbubble behavior in fluids (including seawater)

Applications

Microbubble research and development

Environmental and water treatment studies
Biomedical and biological activity research
Fluid dynamics experiments

Efficient Micro Bubble Technology

Our micro bubble generator is engineered to produce fine bubbles, ranging from 10 to 50 microns, ensuring optimal gas-liquid exchange in water treatment, aquaculture, and more. With precise control over bubble size and flow rates, efficiency and effectiveness are enhanced in every use.

User-Friendly Installation and Operation

Thanks to its compact 18 kg design and portable form, this system is easy to install in various locations. Installation is straightforward, and the automatic/manual switch ensures operational flexibility, accommodating different processes and user preferences.

Durability with Quiet Performance

Constructed with robust materials and certified with an IP55 waterproof rating, the generator is built for long-term reliability even in challenging environments. Its quiet operation, falling below 60 dB, allows for use in sensitive or noise-restricted settings without disturbance.

FAQ's of Micro Bubble Generator:

Q: How do I install the micro bubble generator?

A: The unit is designed for easy installation and portability. Simply connect the 1-inch inlet and outlet to your system, place the generator in a suitable location, and follow the supplied manual to set up the automatic or manual control system. Its compact 18 kg weight allows for quick relocation if necessary.

Q: What applications benefit from using this micro bubble generator?

A: This generator is ideal for water treatment, aquaculture aeration, laboratory mixing, and other gas-liquid diffusion processes. The fine bubble size (10-50 micron) provides enhanced oxygen transfer and mixing efficiency, improving overall process performance.

Q: When should I choose automatic or manual operation?

A: Select automatic mode for continuous or timed operations where minimal supervision is desired. Switch to manual mode for hands-on control during experimental, testing, or custom operation scenarios.

Q: Where can I use this portable bubble generator?

A: With its IP55 waterproof rating and quiet operation (<60 dB), the generator is suitable for both indoor and outdoor industrial applications, as well as environments where noise levels must be controlled.

Q: What process does the generator use to create micro bubbles?

A: It operates at 800-1200 RPM, drawing gas and water through its internal mechanism at a flow rate of 5-20 L/min, producing fine bubbles that disperse evenly in the liquid for efficient gas transfer.

Q: How does using this generator contribute to process performance?

A: The fine micro bubbles increase the surface area for gas exchange, resulting in higher oxygen transfer rates and improved mixing, which benefits applications like wastewater treatment and aquaculture.
