Pitot-Static Probe

Get a Price/Quote

MOQ : 1 Number

Pitot-Static Probe Specification

Equipment Type
Air Data Sensor / Airspeed Probe

Material
Stainless Steel

Processing Type
Precision Machined

Condition
New

Technology
Pitot-Static Measurement Technology

Dimension (L*W*H)
270 mm x 15 mm x 15 mm

Power Mode
Mechanical

Pressure Output
Static and Dynamic Air Pressure

Application
Aerospace, Aviation, Wind Tunnel Testing, Meteorology

Coating Type
Corrosion Resistant Finish

Accessories
Mounting Bracket, Tubing Kit, Installation Guide

Usage Environment
Outdoor/Indoor

Connection Type
Dual Port (Pitot & Static)

Weight
Approx. 350 g

Accuracy
0.5% of Full Scale

Probe Diameter
Approx. 12 mm

Maintenance
Minimal, Easy-to-Clean Tip

Compliance
FAA & EASA Standards

Calibration
Factory Calibrated, Field Recalibration Possible

Installation
Surface Mountable

Operating Temperature Range
-40C to +70C

About Pitot-Static Probe

Overview

A precision Pitot-static probe designed for accurate airspeed and static pressure measurement in wind tunnel and aerodynamic applications. Featuring a rounded-tip total pressure port and multiple static ports, the probe ensures reliable and repeatable flow measurements across a wide range of test conditions.

Key Features

Dual Measurement: Total and static pressure sensing
High Accuracy Design: Rounded tip for stable stagnation pressure capture
Multi-Port Static Measurement: 6 static ports for improved accuracy
Slim Profile: Minimal flow disturbance
Flexible Integration: Compatible with various wind tunnels

Technical Datasheet (Typical)

Geometry

Outer Diameter: 3.175 mm (0.125 in)
Forward Reach (tip to bend): 66 mm (2.6 in)
Length to Bend: 330 mm (13 in)

Pressure Ports

Total Pressure: Rounded-tip inlet
Static Pressure: 6 circumferential ports

Connectivity

Tubing: Supplied for connection to manometers or pressure transducers
Mounting: Compatible with standard probe mounts or custom fixtures

Performance

Application Range: Subsonic to low transonic flows (setup dependent)
Use Case: Airspeed calculation, pressure distribution, calibration
Accuracy: High repeatability with proper calibration

Optional Features

Custom probe lengths and diameters
Integrated pressure sensors or connectors
Specialized coatings or materials
Handcrafted custom probes and models

Applications

Wind tunnel velocity measurement
Airflow diagnostics and calibration
Educational laboratory experiments
General aerodynamic testing

Customization

Each probe can be custom-built to suit specific tunnel configurations, measurement systems, and flow conditions.

High Accuracy and Compliance

Our Pitot-Static Probe offers exceptional measurement accuracy, with an error margin of just 0.5% of the full scale. Built using stainless steel and processed for precision, it adheres to stringent FAA and EASA standards, ensuring safety and reliability for critical aerospace and aviation applications. The corrosion-resistant coating further enhances its durability in demanding environments.

Adaptable for Multiple Applications

This probe is engineered to serve a variety of environments and industries, including aviation, meteorology, and wind tunnel testing. Its surface-mountable design and mechanical operation make it suitable for both indoor laboratories and outdoor test facilities. The combination of a dual-port connection and robust, factory-set calibration ensure flexibility and dependable performance wherever accurate air data measurement is required.

Easy Installation and Maintenance

The Pitot-Static Probe simplifies operation by including a mounting bracket, tubing kit, and a comprehensive installation guide. Its tip is specifically designed for easy cleaning, and minimal routine maintenance is needed due to quality machining and durable materials. With field recalibration capability, users can maximize instrument lifespan and maintain measurement integrity on site.

FAQ's of Pitot-Static Probe:

Q: How do I install the Pitot-Static Probe on my equipment?

A: Installation is straightforward thanks to the included mounting bracket, tubing kit, and detailed installation guide. The probe's surface-mountable design allows for secure attachment to most structures in both indoor and outdoor environments.

Q: What types of environments can the Pitot-Static Probe operate in?

A: This probe functions reliably in a wide temperature range from -40C to +70C, making it suitable for harsh outdoor conditions as well as controlled indoor settings such as wind tunnels, laboratories, and aircraft.

Q: When is recalibration of the probe necessary, and how can it be performed?

A: Though the probe is factory-calibrated for immediate use, field recalibration is possible whenever precision validation is required. Follow the manufacturer's recommended process using qualified calibration equipment to maintain optimal accuracy.

Q: Where can I use this probe in the aerospace and aviation sectors?

A: It is ideal for integration into aircraft, drones, wind tunnel setups, and meteorological stations. The dual-port system facilitates both pitot and static pressure measurement, essential for reliable airspeed and altitude data.

Q: What maintenance is required for the probe?

A: Maintenance is minimal. The stainless steel, corrosion-resistant design requires only occasional cleaning, especially the tip, which is engineered for easy access and cleaning. Regular inspections after heavy use or exposure to contaminants are advised.

Q: How does the dual port system benefit my measurements?

A: The dual port configuration enables simultaneous measurement of static and dynamic air pressure, providing precise airspeed and altitude data essential for aerospace, meteorological, and testing applications.

Q: What are the advantages of the included accessories?

A: The supplied mounting bracket, tubing kit, and installation guide promote hassle-free setup and secure integration with your system, saving time and reducing installation errors.
